Sleeve anchors provide a secure anchoring solution for a variety of applications, from brickwork to structural concrete. When the nut is tightened, these anchors expand against the base material, ensuring a strong connection that effectively distributes load-bearing weight. The controlled expansion design minimizes point loads, making them particularly effective for hollow brick. Made from all-steel construction and available in a galvanised finish, they are pre-assembled for quick installation. Simply drill a hole matching the diameter of the anchor, hammer it through your fixture, and tighten the nut for a secure hold.
×

×
Product Enquiry
You are enquiring about
Anchor Bolts FastenersSleeve Anchors 10 x 100mm GAL Pack 10
Description
Features
- Galvanized finish protects against rust, ensuring longevity for outdoor areas.
- Pre-assembled design allows for quick and efficient setup without the need for extra tools.
- Expands to distribute forces evenly, preventing damage to materials during use.
Specifications
Quantity | 10 |
Anchor Diameter | 10mm |
Drill Size | 10mm |
Length | 100mm |
Finish | Galvanised |
Effective Anchor Depth | 50mm |
Thread Size | M8 |
16.8mm | 5.8kN |
Recommend Tension Load 32MPa (40mm embedment) | Flanged Head Diameter |
Wrench Size | 13mm |
